Rolling Guardrail Barrier Highway Safety Guardrail EVA Rotating Anti-Collision Pier

China Qingdao TaiCheng transportation facilities Co.,Ltd. certification
China Qingdao TaiCheng transportation facilities Co.,Ltd. certification
I am very grateful to the staff of Taicheng for their cooperation. Our guardrail installation is very beautiful, and my customers like it too. Next time I will buy back.

—— Le Thao

I'm Online Chat Now

Rolling Guardrail Barrier Highway Safety Guardrail EVA Rotating Anti-Collision Pier

Rolling Guardrail Barrier Highway Safety Guardrail EVA Rotating Anti-Collision Pier
Rolling Guardrail Barrier Highway Safety Guardrail EVA Rotating Anti-Collision Pier
video play

Large Image :  Rolling Guardrail Barrier Highway Safety Guardrail EVA Rotating Anti-Collision Pier

Product Details:
Place of Origin: China
Brand Name: Tai Cheng
Certification: CCS, ISO,SB
Model Number: RGB
Payment & Shipping Terms:
Minimum Order Quantity: 50m
Price: 160 USD per meter
Packaging Details: Tray, Nude
Delivery Time: 5-8work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 12-15km per month
Detailed Product Description
Usage: Road Traffic Safety Weather Resistance: Excellent
Metal Material: Q235 Hot-Dip Galvanizing Material: EVA
High Light:

Highway Safety Rolling Guardrail Barrier

,

EVA Rotating Anti Collision Pier

,

Q235 Highway Safety Guardrail

1.Product description



  The rotating guardrail adopts the "one column and four columns" method. By strengthening the performance and installation method of the columns and guardrails, it can effectively prevent cars from passing through the guardrail and driving out of the driving lane. It pioneered the use of a rotating structure to support the elastic, anti-collision and wear-resistant rotating barrel on the column, so that the rotating barrel can rotate freely on the column. This free rotation of the rotating barrel decomposes the impact force of the car. In this way, the impact force perpendicular to the direction of the guardrail is decomposed into the direction parallel to the guardrail, and is effectively absorbed and reduced by the rotating barrel, thereby effectively reducing the consequences of traffic accidents.



Rolling Guardrail Barrier Highway Safety Guardrail EVA Rotating Anti-Collision Pier 0



2.The functions of rotating anti-collision guardrail



  When a car is about to collide and rush towards the guardrail, due to the rotation of the roller, the impact energy of the car is converted into rotational energy parallel to the guardrail, achieving the effect of overcoming rigidity with softness. As a longitudinal energy-absorbing structure, the rotating anti-collision wave guardrail absorbs collision energy through self-deformation or vehicle climbing, thereby changing the vehicle's driving direction and preventing the vehicle from crossing the road or entering the opposite lane. This will minimize the damage to the occupants. It is particularly prominent in preventing vehicles from crossing the road or crossing the central divider into the opposite lane, and preventing vehicles from getting out from under the guardrail. In the event of a collision, the degree of damage to passengers will be greatly reduced.



Rolling Guardrail Barrier Highway Safety Guardrail EVA Rotating Anti-Collision Pier 1



3.our company



  Qingdao Taicheng Transportation Facilities Co., Ltd. is a technological innovation enterprise invested by Henger Group. Its headquarters is located in Jinkou Industrial Park, Qingdao. Taicheng Transportation has an innovative scientific research team, advanced manufacturing technology, first-class production facilities, and perfect testing methods. , reliable product quality, enthusiastic after-sales service, devoted to the great cause of improving China's road safety.



  The impact-resistant and energy-absorbing rotating guardrail independently developed and designed by Taicheng Transportation has broken the technological monopoly of Korean and American countries and filled the market gap of China's rotating guardrail. The product has more than 20 national patents, and has successfully passed the collision test of small cars (family cars), buses and large trucks in the highway test site of the Ministry of Communications, and the test results and collision data are at the international leading level.



Rolling Guardrail Barrier Highway Safety Guardrail EVA Rotating Anti-Collision Pier 2Rolling Guardrail Barrier Highway Safety Guardrail EVA Rotating Anti-Collision Pier 3



  The new series of rotating anti-collision barriers have been widely used in South Korea, Japan, the United States, the United Arab Emirates and other countries. The accident rate, economic loss rate and accident fatality rate of the installed road section have been reduced by more than 95%, which has greatly protected the lives of pedestrians. Property safety provides a reliable guarantee and strong shield for road safety. It is believed that in the near future, the new type of rotating anti-collision guardrail will be popularized on China's highways and accident-prone sections, introducing innovative protection design for China's road environment, bringing leap-forward protection effects for road safety, and becoming a life project for the benefit of future generations. .



  The company will always adhere to the corporate tenet of "not forgetting the original intention, people-oriented, and technological innovation", to build a first-class transportation facility enterprise with international competitiveness, to provide the society with high-quality new rotating anti-collision guardrails, and to protect the road safety of the country and the world. convoy.



Rolling Guardrail Barrier Highway Safety Guardrail EVA Rotating Anti-Collision Pier 4



4.Product components



The rotating anti-collision guardrail is composed of rotating barrels, beams, columns, reflective strips, casings, gyroscopes and connectors.



Rolling Guardrail Barrier Highway Safety Guardrail EVA Rotating Anti-Collision Pier 5



5.Installation method of rotating anti-collision guardrail



(1) When installing the rotating anti-collision guardrail, it is spliced to each other through splicing bolts and fixed to the columns or beams by connecting bolts. The splicing direction of corrugated beams is the key to installation. During construction, ensure that the overlapping direction should be consistent with the driving direction.

(2) The rotating anti-collision guardrail should be continuously adjusted during the installation process, so the connecting bolts and splicing bolts should not be tightened prematurely so that the long round holes of the corrugated beam can be used for timely adjustment during the installation process. This will allow it to form a smooth linear shape, thereby avoiding local unevenness.



Rolling Guardrail Barrier Highway Safety Guardrail EVA Rotating Anti-Collision Pier 4Rolling Guardrail Barrier Highway Safety Guardrail EVA Rotating Anti-Collision Pier 7

(3)When installing, the top surface of the rotating anti-collision guardrail should be coordinated with the vertical curve of the road. And check the linear shape of the guardrail. When it is determined that the linear shape is relatively straight and smooth, the bolts can be tightened finally.



Rolling Guardrail Barrier Highway Safety Guardrail EVA Rotating Anti-Collision Pier 8
