Product Details:
Payment & Shipping Terms:
|
| Material: | Q235 Q345,EVA And PU Foam (Polyurethane) | Color: | Yellow,Orange |
|---|---|---|---|
| Application: | Collision Avoidance; Highway Protect; Road Traffice Safty,Anticollision,bridge | Type: | Double Buckets Or Single Bucket |
| Feature: | High Intensity,Durable,anti-corrosion | Surface Treatment: | Hot Dipped Galvanized |
| Packing: | Standard Export Package |
Product color: The color is bright and bright, and can be sprayed into various colors according to needs, such as yellow, orange, red and blue.
Scope of use: Anti-collision barrels are mainly placed on highways and urban roads where collisions between cars and fixed facilities in the road are likely to occur, the central isolation of the road, intersections, highway toll station square guidance isolation, road turns, roads and elevated roads Import and export, under the wire rope safety fence on the side of the road, etc.
Product Introduction
| name | highway guardrail safety roller barrier | use | road safety |
| size | 4130*310*81*2.75 | standard | American standard |
| material | Q345B or Q235B | feature | anti-corrision |
| certificate | ISO SGS BV CE | treatment of surface | hot dip galvanized |
Product Usage:
1. The anti-collision pad under the wire rope safety fence on the side of the road is used to protect the safety of people and reduce the impact in the event of a traffic accident.
2. The anti-collision barrel can play the role of isolation warning and anti-collision because of its bright color.
3. It can buffer the accidental collision with the vehicle, effectively reduce the impact force, and greatly reduce the damage of the vehicle and people.
Product Parameters
| No. | Name | Specifications(mm) | Material |
| 1 | Roller | 345*490/350*510(Customized) | Polyurethane |
| 2 | Post | 140*2000*4.5(Customized) | Q235 |
| 3 | PVC Tube | 160*500*6.5(Customized) | PVC |
| 4 | Beam | 100*80*4.0 | Q235 |
| 5 | Rolling Circle | 182×145×6.0 | Polymer Ethylene |
| 6 | End Socket | 1300×230×4.0 | Q235 |
| 7 | Post Cap | 145×145 | Rubber |
| 8 | Bolt | M18*120 | Q235 |
| M18*180 | Q235 | ||
| M18*80 | Q235 | ||
| 9 | Nut | M20 | Q235 |
| Item | Specifications |
| Apparent Density (KG/m³) | ≥125 |
| Tensile Strength(MPa) | ≥1.15 |
| Elongation(%) | ≥320 |
| Compression Permanent Distortion (%) | ≥38 |
| Resilience(%) | ≥72 |
Features:
1. The wear resistance is 3-5 times that of natural rubber.
2. The oil resistance is 4 times better than that of NBR.
3. High mechanical strength, its tear strength, tear strength and load bearing capacity are many times higher than ordinary rubber.
4. Excellent acid and alkali resistance, low temperature resistance, radiation resistance and solvent resistance
5. High bonding strength with metal skeleton board.
6. The service life is relatively high, which can last for decades, and the cost performance is very high.
FAQ
1. Are you a trader or factory?
Yes,our factory is in Shandong,China.
2. How can i get a sample if i want to test the quality?
Yes,we would offer the samples.If you want to test the quality,please let me know and i would arrange you the samples.
3. How long is your delivery time?
We would offer you a best delivery time.we have a big factory,and our output would be more than 100 thousand tons per month.
4. What is your payment terms?
We accept T/T, L/C.
