Product Details:
Payment & Shipping Terms:
|
| Name: | Highway Safety Roller Barrier | Material: | EVA |
|---|---|---|---|
| MOQ: | 100M | Color: | Customized Color |
| Model: | Single/Double Roller | Spacing: | 700/1000mm |
| Certificate: | SB Grade Certificate | Surface Treatment: | Galvanized |
| High Light: | Traffic Safety EVA Roller Barrier,Roadway Safety EVA Roller Barrier,EVA Anti Crash Barrier |
||
Composed:
Roller Barrel, beam, column, reflective strip, sleeve, convoluted ring, U-shaped connector, bolt, column cap, end
Material:
Roller barrier system is made of high-grade environmental protection material EVA foam, which has the characteristics of flame retardancy, acid and alkali resistance, and high temperature resistance.
Metal parts are hot-dip galvanized materials.
Features:
1. The rotating barrel has the characteristics of flame retardancy, acid and alkali resistance and not easy to age.
2. The color of the rotating barrel can be customized according to customer needs.
3. The distance between the two barrels of the rotating guardrail is usually 0.7M and 1M.
4. The EVA foam itself has high elasticity, and when the vehicle knocks down the guardrail, the rotating barrel will rebound, so that the maintenance cost of the rotating guardrail is lower than other guardrails.
Application
1. Highway ramp
The ramp is also a place where traffic accidents are prone to occur. Because the road is narrow, it is a test of the driver's driving skills. When a novice driver is driving on the ramp, traffic accidents are likely to occur, ranging from damage to the vehicle to breaking the guardrail and rushing down the hill. Therefore, rotating guardrails are used on many high-speed ramps.
2. Road bend area
Usually there will be a lot of vehicles coming and going at the turning. When the vehicle is driving at the turning at high speed, traffic accidents will easily occur. Therefore, our protective guardrail will be installed at the turning of the road in many areas, which can effectively protect the safety of drivers and passengers.
3. Cliff edge
The edge of the cliff is the place where traffic accidents are most likely to occur. When the vehicle is driving on the highway at the edge of the cliff at high speed, it is a test of the driver's control of the road conditions. If there is a slight mistake, the driver will break through the guardrail and rush down the cliff , so it is necessary to install a rotating guardrail on the edge of the cliff, because the rotating guardrail can absorb energy and convert kinetic energy into rotational energy, thereby forcing the vehicle to continue moving forward at a slow speed.
4. Fork in the road
There are many vehicles passing through the fork, and the use of traditional guardrails may not protect the personal safety of drivers and passengers well.
The rotating guardrail itself is brightly colored, which can warn drivers and also play a decorative role. The rotating guardrail can adapt to all environments and weathers.
Technical Parameters:
| No. | Name | Specifications(mm) | Material |
| 1 | Roller | 345*490/350*510(Customized) | Polyurethane |
| 2 | Post | 140*2000*4.5(Customized) | Q235 |
| 3 | PVC Tube | 160*500*6.5(Customized) | PVC |
| 4 | Beam | 100*80*4.0 | Q235 |
| 5 | Rolling Circle | 182×145×6.0 | Polymer Ethylene |
| 6 | End Socket | 1300×230×4.0 | Q235 |
| 7 | Post Cap | 145×145 | Rubber |
| 8 | Bolt | M18*120 | Q235 |
| M18*180 | Q235 | ||
| M18*80 | Q235 | ||
| 9 | Nut | M20 | Q235 |
| Item | Specifications |
| Apparent Density (KG/m³) | ≥125 |
| Tensile Strength(MPa) | ≥1.15 |
| Elongation(%) | ≥320 |
| Compression Permanent Distortion (%) | ≥38 |
| Resilience(%) | ≥72 |
| Chemical Composition | |||||||||||||||||
| C | Si | P | S | Mn | Ni | Cu | Cr | B | V | Mo | W | Al | Co | Pb | Se | Te | Bi |
| 0.18% | 0.001% | 0.022% | 0.013% | 0.38% | 0.002% | 0.001% | 0.002% | 0 | 0 | 0.001% | 0.001% | 0.002% | 0.001% | 0.001% | 0.001% | 0.02% | 0.03% |
