EVA Rotating Rolling Guard Barrier Elastic Galvanized Powder Coated

China Qingdao TaiCheng transportation facilities Co.,Ltd. certification
China Qingdao TaiCheng transportation facilities Co.,Ltd. certification
I am very grateful to the staff of Taicheng for their cooperation. Our guardrail installation is very beautiful, and my customers like it too. Next time I will buy back.

—— Le Thao

I'm Online Chat Now

EVA Rotating Rolling Guard Barrier Elastic Galvanized Powder Coated

EVA Rotating Rolling Guard Barrier Elastic Galvanized Powder Coated
EVA Rotating Rolling Guard Barrier Elastic Galvanized Powder Coated

Large Image :  EVA Rotating Rolling Guard Barrier Elastic Galvanized Powder Coated

Product Details:
Place of Origin: Shandong,China
Brand Name: Qingdao Henger
Certification: CIC
Model Number: HE-SRG01
Payment & Shipping Terms:
Packaging Details: nude packing or customized
Delivery Time: 30 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 meters per month
Detailed Product Description
Material: EVA Color: Yellow,Orange,Red
Application: Roadway Safety Surface Treatment: Galvanized + Powder Coated
Product Name: Safety Rolling Traffic Barrier/Guard Rail/safety Roller Type: Straight Barrier
Feature: Great Corrosion Resistant,High Intensity Packing: Standard Export Package
High Light:

Powder Coated Rolling Guard Barrier

,

Galvanized Rolling Guard Barrier

,

Elastic EVA Rotating Guard Barrier

EVA Rotating Rolling Guard Barrier Elastic Galvanized Powder Coated

Introduction

In order to avoid the vehicle in a collision when driving out of the road range, to reduce the degree of traffic accident damage, the central divider of the highway and both sides of the road are set up with anti-collision guardrail. The common form of anti-collision guardrail is concrete guardrail, waveform beam guardrail and cable guardrail, which, cable guardrail is a flexible guardrail, which absorbs the energy generated by the vehicle collision is limited, so less application.

At present, the main application of the highway is the concrete guardrail and waveform beam guardrail. The former belongs to the rigid guardrail, the latter belongs to the semi-rigid guardrail, these two guardrails have a better anti-collision effect, but in the vehicle after the collision, or will produce a large damage. At the same time, due to these two guardrails on the contour marker area is small, with the passage of time will produce a lot of dust, resulting in the guardrail reflective warning effect getting worse.

In order to improve the safety of passing vehicles, the driver's alertness, especially accident-prone areas and small radius ramps vehicle driving safety. Rotating collision barrier after more than a year of pilot application, from the traffic police, road administration and the feedback from the barrier department, the pilot section of traffic accident frequency significantly reduced, the degree of damage caused by the accident also significantly reduced.
EVA Rotating Rolling Guard Barrier Elastic Galvanized Powder Coated 0
Rotating anti-collision guardrail principle of work
Rotating collision barrier to change the traditional guardrail single side of the waveform beam type, using a column double side guardrail, that is, in the column on both sides of the installation of waveform beam guardrail. The middle of the installation of rotating anti-collision barrel, in the rotating barrel of the upper and lower are installed waveform guardrail, so that a column will be installed on the four-waveform beam, that is, "a column of four columns" strengthen the type of guardrail. This enhanced guardrail device can effectively prevent cars from crossing the guardrail out of the road, and the rotating barrel posted on the two eye-catching reflective strips (circle), can maximize the warning to drivers and passengers to pay attention to safety, effectively reduce the rate of traffic accidents. When the vehicle hits the guardrail, first will collide with the rotating barrel contact, then, the vehicle with the rotating barrel rotation, driving speed gradually decreased, at the same time, the impact energy generated by the collision is rotating barrel significantly absorbed, can effectively reduce the consequences of traffic accidents.
EVA Rotating Rolling Guard Barrier Elastic Galvanized Powder Coated 1
The main components of rotating collision avoidance guardrail
The rotating collision barrier is mainly composed of columns, swing circles, rotating barrels, beams, waveform beams, reflective strips and the corresponding connecting parts. The rotating barrel is made of ethylene vinyl acetate copolymer (EVA) and polyurethane composite material, which is elastic, anti-collision and wear-resistant and can effectively avoid the rotating barrel from being broken by impact. At the same time, the good recovery force of the rotating bucket also ensures that it can be quickly restored to its original state after a serious impact. In addition, the color of the rotating barrel is bright, white, yellow, orange, etc. The barrel was chosen by Suzhou Bypass Expressway Co., Ltd. is orange, which has high brightness reflection effect and eye-catching function, which can effectively improve the driver's attention and reduce the accident rate, thus ensuring the safety of the vehicle.
                      EVA Rotating Rolling Guard Barrier Elastic Galvanized Powder Coated 2
W Beam Rolling Guardrail Barrier Accident Car Transportation Facilities Guardrail 4
Construction process of rotating anti-collision guardrail

·Column installation

Use the pile driver to drive the column vertically into the road. If the road base is particularly hard, the column can't go down, use the drilling machine to punch the hole and then install the column. After the verticality and elevation check of the column is completed, the column will be backfilled and pounded with C20 concrete.
·U-frame installation
The two U-frames are fixed with M20×180mm hexagonal bolts on the Φ20 counterbore of the lower part of the column. It should be noted that the nuts need not be tightened for the later installation and commissioning.
·Lower guardrail installation
First, along the U-slot will be M20 × 60mm half-round head waist neck bolts with square pad buckle into, then, the guardrail first and last two bolts and U-frame on the U-slot fixed, and then install the other bolts.
·The installation of the gyratory ring
After the installation of the two lower guardrails, on the column set on the swing ring.
·Installation of swing barrel
In each column on the set of a swing barrel, and then on the swing barrel on the swing ring.
·The installation of the upper guardrail
The installation method is the same as the installation method of the lower guardrail. First, along the U groove will be M20 × 60mm half round head waist neck bolts with square pad buckle into, and then, all the bolts on the guardrail will be inserted into the top hole of the column, with nuts fixed tight.
·Between the guardrail connection
Use the connecting frame to connect the adjacent guardrail, after a section of guardrail is installed, the connecting frame will be inserted into one end of the guardrail and fixed, so that the next section of the guardrail splices.
·Guardrail and the end of the connection
The end will be set into the guardrail, with M20 × 140mm bolts to fix it.
·The installation of the end cover
After the above installation steps are completed, adjust the guardrail line, tighten all the nuts, the end cover set on the column can be fastened.


Product Parameters



No. Name Specifications(mm) Material
1 Roller 345*490/350*510(Customized) Polyurethane
2 Post 140*2000*4.5(Customized) Q235
3 PVC Tube 160*500*6.5(Customized) PVC
4 Beam 100*80*4.0 Q235
5 Rolling Circle 182×145×6.0 Polymer Ethylene
6 End Socket 1300×230×4.0 Q235
7 Post Cap 145×145 Rubber
8 Bolt M18*120 Q235
  M18*180 Q235
  M18*80 Q235
9 Nut M20 Q235



Item Specifications
Apparent Density (KG/m³) ≥125
Tensile Strength(MPa) ≥1.15
Elongation(%) ≥320
Compression Permanent Distortion (%) ≥38
Resilience(%) ≥72


8. FAQ

1. Are you a trader or factory?
Yes,our factory is in Shandong,China.

2. How can i get a sample if i want to test the quality?
Yes,we would offer the samples.If you want to test the quality,please let me know and i would arrange you the samples.

3. How long is your delivery time?
We would offer you a best delivery time.we have a big factory,and our output would be more than 100 thousand tons per month.

4. What is your payment terms?
We accept T/T, L/C.


Safety Anti Collision Bucket Roller Barrier Shipping Details



No. Product Specifications 40*HQ Container Shipping Capacity
1. 1000 mm Column Space Barriers size : 350*500 MM 280 Meters
2. 700 mm Column Space Barriers size : 350*500 MM 240 Meters



Highway Anti-collision Polyurethane Rotating Barrier Introduction



The anti-collision road roller guardrail is a new type of product. It is assembled with PU/EVA rollers and galvanized steel columns and beams. But it is different from w-beam guardrail. It can absorb the impact and guide the vehicle to the direction of the road through the rollers, convert the impact energy into forward kinetic energy, so as to prevent major accidents, and can reduce the damage to the vehicle and human body in the event of an accident. Moreover, the rollers are lighter than the w-beam guardrail, and the installation is more convenient. Recoverable after attachment, easy to maintain. long lasting.



Product Name Roller barrier
Material Polyurethane, hot galvanized steel
Color Yellow, Orange, As you required
Used Highway, tunnel, bridge
Features Anti-corrosion, high tempreture resistance, low friction
