Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier

China Qingdao TaiCheng transportation facilities Co.,Ltd. certification
China Qingdao TaiCheng transportation facilities Co.,Ltd. certification
I am very grateful to the staff of Taicheng for their cooperation. Our guardrail installation is very beautiful, and my customers like it too. Next time I will buy back.

—— Le Thao

I'm Online Chat Now

Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier

Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier
Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier

Large Image :  Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier

Product Details:
Place of Origin: Qingdao
Brand Name: Taicheng
Certification: ccs
Model Number: RG-SA
Payment & Shipping Terms:
Minimum Order Quantity: 100M
Packaging Details: nude
Delivery Time: 30working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500m per months
Detailed Product Description
Material: EVA,Q345 Color: Yellow,Orange
Application: Roadway Safety Surface Treatment: Hot Dipped Galvanized
Product Name: Safety Rolling Traffic Barrier/Guard Rail/safety Roller Name: Traffic Safety Equipment Construction Plastic Road Traffic Barrier
Size: D350*H500mm(Single),request,Customized Technology: Cold Rolling
Certificate:: SB,ISO9001,CIC Warranty: 12 Months
Standard: JT/T281-2007 Advantage: Easy Replace,the Directly Manufacturer And Exported Company,Rustproof,long Life Time
D350*H500mm(Single),request,Customized: Pallet,Standard Export Package Or As Per Client's Requirements,Standard Export Package Weight: Weight
Height: 900mm,81-85mm,1100mm Length: 510mm,2000mm/1250mm,2320-5320mm
Type: Double Buckets Or Single Bucket,w-beam,three Waves Beam,single&double Barrel,Single Barrel
High Light:

Roller Metal Beam Crash Barrier

,

Orange Metal Beam Crash Barrier

,

Roadway Rolling Guardrail Barrier

Highway Safety Roller Barrier Metal Beam Crash Barrier Guardrail Barrier

Qingdao Taicheng Transportation Facilities Co., Ltd

Company Qualification
As a manufacturer specializing in the production of new road anti-collision guardrails,we have obtained more than 20 national production patents, and in July 2018 we passed the SB-class rotating guardrail real vehicle collision and obtained relevant reports.Qingdao Taicheng Transportation Facilities Co., Ltd As the earliest and most professional manufacturer of rotating guardrails, we have already cooperated with the State Council and the Ministry of Communications of many countries to reach a national-level project installation and construction plan.Our company is the first Chinese export-oriented new road anti-collision guardrail currently . Ourrotating guardrails had already exported to Jordan, Brazil, the Philippines, Indonesia and other countries, and provide a strong guarantee for local road safety


                                  Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier 0


Hot sale highway anti-collision rotating guardrail

Introduction
Domestic and foreign traffic accident research data show that, reasonably set to meet the protection requirements of the guardrail, can effectively reduce the vehicle out of the roadside guardrail or through the secondary collision with the chances of collision, so as to avoid unnecessary property damage and casualties. Rolling crash barrier is mainly used in small radius curve section, tunnel entrance transition, interchange exit triangle end and other dangerous sections. The increase of car ownership makes the road bear the pressure of the vehicle running too much, easy to appear sudden traffic accidents. In the highway traffic accidents, a large number of accidents with the road on both sides of the guardrail collision-related. Guardrail design can make the runaway vehicle in collision with the guardrail to return to the normal direction of travel, maximum absorption of impact energy, reduce the injury to the driver and passengers.



Ethylene Vinyl Acetate Copolymer Metal Beam Crash Barrier Roller Safety Barrier Box Beam Guardrail

                              Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier 1                                                            Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier 2

Minimum Setting Length of Rotary Collision Guardrail




Highway grade Set separately(m) Lap setting(m)
Highway, First Class Highway 70 15
Grade two highway 48 10
Level 3 and 4 Highways 28





Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier 3





1.Rotary anti-collision guardrail can be used as roadbed side guardrail, central partition guardrail, as well as bridge guardrail for small bridges, passages and culverts.



2.When the anti-collision surface of the rotary anti-collision guardrail does not coincide with the elevation of the curb stone, the height of the curb stone should be increased.

3.The compactness of roadbed in roadside and central partition zone should be strengthened by concrete foundation when necessary.

4.Transition treatment should be carried out between the rotary anti-collision guardrail and other types of guardrail.

5.Rotating barrel should be yellow, indicating warning.

6.When the revolving anti-collision guardrail is set on the left side or the central partition of the lane, the color of the reflective strip should be yellow, while the color of the reflective strip should be white when it is set on the right side of the lane.
Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier 4
The optional anti-collision guardrail is used as the end guardrail in the upstream direction of other guardrail, As shown in the figure.
Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier 5
When the radius of the horizontal curve is less than that specified in the table below, it is advisable to install a rotating anti-collision guardrail in the section of the horizontal curve.




The rotating guardrail is mainly composed of column, swing circle, rotating barrel, cross beam, waveform beam, reflective strip and corresponding connecting parts. The rotating barrel is made of a composite material of ethylene vinyl acetate copolymer (EVA) and polyurethane, which is elastic, impact resistant and wear resistant and can effectively prevent the rotating barrel from being shattered upon impact. The resilience of the barrel also ensures that it can be quickly restored to its original state after a severe impact. The barrel chosen by Suzhou Bypass Expressway Co., Ltd. is orange, which has a high brightness reflection effect and eye catching function, which can effectively improve the driver's attention and reduce the incidence of accidents, thus ensuring the safety of vehicles.





Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier 6

Features

(1) Fast opening.

The pluggable and removable structure enables 12 m (2 sections) to be opened and pushed in 3 minutes in case of emergency, far better than the norm of 10 m in 10 minutes.
(2) Safety upgrade.

Through rotational friction, the instantaneous impact energy is transformed into rotational energy and friction energy, effectively reducing the damage to the vehicle and the degree of injury to personnel.
(3) Material saving.

The simple shape of the product greatly saves material costs, using about 78 kg of material per linear metre, which is 50% to 80% of the material used in similar products in the current market.

Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier 7
(4) Beautiful shape.

The beautiful shape and beautiful rotating barrels have a good sight line guidance function, which can improve the road appearance and effectively ease the
The effect is more obvious especially at night and in rainy days.
(5) Easy to install.

The compact design of the product allows for easy installation on site after the unit has been assembled, greatly reducing the time spent on site and effectively reducing the risk of road-related operations.
(6) Simple maintenance.

The rotating bucket is made of EVA composite material, which is resistant to chemical corrosion, ageing and weathering, and is not easily damaged by vehicle impact, and does not need to be replaced during its service life (10 years).

Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier 8
Production Qualification And Test Report

Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier 9
 Product Components And Specifications

The rotary anti-collision guardrail is composed of rotating barrel, beam, column, reflective strip, casing, rotating coil and connecting piece.he exploded view is as follows:

Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier 10

Main components
The rotating collision guardrail is mainly composed of column, rotating barrel, casing, rubber cushion, swivel ring, beam, reflective strip and bolt. The side view of the guardrail is shown in the figure, using a column and four columns of the installation method.

Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier 11

Composition
The rolling safety barrier is made of ethylene vinyl acetate copolymer (EVA) and polyurethane composite material, which is elastic, impact-resistant and wear-resistant and can effectively prevent the rotating barrel from being shattered upon impact, and the good recovery force of the rotating barrel also ensures that it can quickly return to its original state after a serious impact.

Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier 12

Rotary anti-collision guardrail constitutes the outline - the deviation of the outer dimensions of the rotating anti-collision guardrail member is allowed 5%

d 151+2 -2
h1 110+2 -2
h2 50+1 -1
h3 80+2 -2


Production Capacity

For the new rotating bucket guardrail, our capacity is 12-15km per month , which can meet the requirements of all urgent orders.


Shipping Details



No. Product Specifications

40*HQ Container



Shipping Capacity

1.

1000 mm Column Space



Barriers size : 350*500 MM

280 Meters
2.

700 mm Column Space



Barriers size : 350*500 MM

240 Meters



Test Situation





Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier 13





A.1 Rotating Barrel
The shape of the rotating barrel is shown in Figure A.1 ,The nominal size and
allowable deviation shall comply with the requirements of Table A.1
Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier 14

                                        Figure A.1 Appearance


Roadway Safety Roller Metal Beam Crash Barrier Guardrail Barrier 15
                                                 Figure A.2 Structural design

Production Capacity
For the new rotating bucket guardrail, our capacity is 12-15km per month , which
can meet the requirements of all urgent orders.
