PU EVA Rotating Guardrail Anticollision With Galvanized Highway Crash Barrier

PU EVA Rotating Guardrail Anticollision With Galvanized Highway Crash Barrier
PU EVA Rotating Guardrail Anticollision With Galvanized Highway Crash Barrier PU EVA Rotating Guardrail Anticollision With Galvanized Highway Crash Barrier PU EVA Rotating Guardrail Anticollision With Galvanized Highway Crash Barrier PU EVA Rotating Guardrail Anticollision With Galvanized Highway Crash Barrier PU EVA Rotating Guardrail Anticollision With Galvanized Highway Crash Barrier

Large Image :  PU EVA Rotating Guardrail Anticollision With Galvanized Highway Crash Barrier

Product Details:
Place of Origin: CHINA
Brand Name: TC
Certification: ISO
Model Number: 0015
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Payment Terms: W Beam Rolling Guardrail Barrier Accident Car Transportation Facilities Guardrail
Supply Ability: 100 Meters Per 25 Days Or More Less Time
Detailed Product Description
Brand Name: Taicheng Product Name:: Safety Roller Barrier
Material: PU/EVA+Galvanized Beam Usage: Road Traffic Safety
Size: 1.2 M*1 M* 1.2 M Or Custom Color: Yellow,Orange
High Light:

PU EVA Rotating Guardrail

,

Anticollision EVA Rotating Guardrail

,

Galvanized Highway Crash Barrier

PU EVA Rotating Guardrail Anticollision With Galvanized Highway Crash Barrier

The "one column and four columns" method is adopted, and the performance and installation method of the column and the guardrail are strengthened to effectively prevent the car from passing through the guardrail and driving out of the driving lane. And a rotating structure is adopted to support the elastic and anti-collision and wear-resistant rotating barrel on the column, so that the rotating barrel can rotate freely on the column. The impact force of the direction is decomposed into the direction parallel to the guardrail, which is effectively absorbed and reduced by the rotating barrel, thereby effectively reducing the consequences of traffic accidents.



PU EVA Rotating Guardrail Anticollision With Galvanized Highway Crash Barrier 0PU EVA Rotating Guardrail Anticollision With Galvanized Highway Crash Barrier 1



Product Parameters



No. Name Specifications(mm) Material
1 Roller 345*490/350*510(Customized) Polyurethane
2 Post 140*2000*4.5(Customized) Q235
3 PVC Tube 160*500*6.5(Customized) PVC
4 Beam 100*80*4.0 Q235
5 Rolling Circle 182×145×6.0 Polymer Ethylene
6 End Socket 1300×230×4.0 Q235
7 Post Cap 145×145 Rubber
8 Bolt M18*120 Q235
  M18*180 Q235
  M18*80 Q235
9 Nut M20 Q235







Item Specifications
Apparent Density (KG/m³) ≥125
Tensile Strength(MPa) ≥1.15
Elongation(%) ≥320
Compression Permanent Distortion (%) ≥38
Resilience(%) ≥72






Product Structure



Parts and Installation:

1) Column: It is driven into the roadbed and is the main force-bearing component.

2) Beam: It is used for the connection between the columns and to fix the rotating barrel.

3) Rotary barrel: It is fixed between the upper and lower beams and can be rotated around the column. The main materials are EVA (ethylene-ester acid copolymer) and polyurethane.

4) Sleeve: installed on the inner wall of the rotating barrel, the contact part of the rotating function.

5) Gyratory ring: Installed between the rotating barrel and the beam to balance and promote rotation.

6) Connecting frame: used for connection between beams.

7) U-shaped frame: connect the beam and the column to fix the beam.

8) Pad buckle: Lined with the beam and connected to the U-shaped frame.

9) Hoop: connecting beam and column, used to fix the beam, suitable for specific models.

10) Reflective strips.•It is a reflective film, which is pasted on the rotating barrel and plays an inductive role.


PU EVA Rotating Guardrail Anticollision With Galvanized Highway Crash Barrier 2



Key Features

  • Easy installation and maintenance on curved road
  • The high-elastic synthetic resin roller is hardly damaged by impact. (Cover: PE, Core: Urethane)
  • Powder coating on rails with various colors is available upon request.
  • Minimizes damage on motorists and vehicles with rollers and dual guardrails.

PU EVA Rotating Guardrail Anticollision With Galvanized Highway Crash Barrier 3PU EVA Rotating Guardrail Anticollision With Galvanized Highway Crash Barrier 4PU EVA Rotating Guardrail Anticollision With Galvanized Highway Crash Barrier 5
