Double Buckets Q235 Q345 Road Rolling Barrier Customizable

China Qingdao TaiCheng transportation facilities Co.,Ltd. certification
China Qingdao TaiCheng transportation facilities Co.,Ltd. certification
I am very grateful to the staff of Taicheng for their cooperation. Our guardrail installation is very beautiful, and my customers like it too. Next time I will buy back.

—— Le Thao

I'm Online Chat Now

Double Buckets Q235 Q345 Road Rolling Barrier Customizable

Double Buckets Q235 Q345 Road Rolling Barrier Customizable
Double Buckets Q235 Q345 Road Rolling Barrier Customizable
video play

Large Image :  Double Buckets Q235 Q345 Road Rolling Barrier Customizable

Product Details:
Place of Origin: Qingdao
Brand Name: Taicheng
Certification: SB,ISO
Model Number: 02
Payment & Shipping Terms:
Minimum Order Quantity: 100m
Packaging Details: Pallet / wooden boxes / Suitable packaging
Delivery Time: 15-20 Days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 100 Meters Per 25 Days Or More Less Time
Detailed Product Description
Material: Q235 Q345,EVA And PU Foam (Polyurethane) Color: Yellow,Orange
Application: Highway Usage: Road Traffic Safety
Type: Double Buckets Or Single Bucket,single&double Barrel,Single Barrel Advantage: Easy Replace,the Directly Manufacturer And Exported Company,Rustproof,long Life Time
High Light:

Q345 Road Rolling Barrier

,

Customizable EVA Road Rolling Barrier

,

Double Buckets Roller Crash Barrier

High Quality Customizable Road Rolling Barrier





1. Product Introduction

Rolling system with "one upright four guardrails", can prevent the car through the fence, out of the driving lane effectively by strengthening the performance and installation of upright and guardrails. Rolling system use a rotating structure, install the roller barrier on the upright and make it rotate freely. This free rotation can disassemble the force of percussion from the car. And it will be adsorbed and reduced by the roller barrier effectively. So it can decrease the influence caused by traffic accidents. rolling system will create a new traffic protection way.
Highway Rolling Guardrail Barrier For Vehicle Traffic Protection 0

Double Buckets Q235 Q345 Road Rolling Barrier Customizable 1
2. Product Parameters

No. Name Specifications(mm) Material
1 Roller 345*490/350*510(Customized) Polyurethane
2 Post 140*2000*4.5(Customized) Q235
3 PVC Tube 160*500*6.5(Customized) PVC
4 Beam 100*80*4.0 Q235
5 Rolling Circle 182×145×6.0 Polymer Ethylene
6 End Socket 1300×230×4.0 Q235
7 Post Cap 145×145 Rubber
8 Bolt M18*120 Q235
  M18*180 Q235
  M18*80 Q235
9 Nut M20 Q235



Item Specifications
Apparent Density (KG/m³) ≥125
Tensile Strength(MPa) ≥1.15
Elongation(%) ≥320
Compression Permanent Distortion (%) ≥38
Resilience(%) ≥72

Highway Rolling Guardrail Barrier For Vehicle Traffic Protection 1



3. How safety roller barrier works?




1. The rotating barrel converts great shock from vehicle collision to rotational energy to absorb shock.
2. Upper and lower frames adjust tires of large and small vehicles to prevent the steering system function loss.
3. The three-dimensional structure of D-shaped frame and buffering bracket distribute and absorb the 2nd shock.
4. Props at an interval of 0.7 m increase bearing power to prevent accident vehicles from going over the guardrail and turning over into a dangerous area.
5. The product has a rotating barrel made of EVA with excellent shock absorption power, three-dimensional buffering frames and dense props supporting the frames.
