New Road Crash Barrier ISO Standard Rolling Guardrail Barrier

New Road Crash Barrier ISO Standard Rolling Guardrail Barrier

Brand Name: Taicheng
Model Number: 04
MOQ: 100m
Payment Terms: T/T, L/C, Western Union, MoneyGram
Detail Information
Place of Origin:
Qingdao
Certification:
ISO
Color:
Yellow,Orange,Red
Application:
Roadway Safety,Highway
Surface Treatment:
Hot Dipped Galvanized
Feature:
Great Corrosion Resistant,Easily Assembled
Packing:
Standard Export Package
Advantage:
The Directly Manufacturer And Exported Company,Strong & Durable
Packaging Details:
Standard Export package
Highlight:

ISO Standard Rolling Guardrail Barrier

,

Road Safety Rolling Guardrail Barrier

,

350mm Road Crash Barrier

Product Description

New Road Crash Barrier ISO Standard Rolling Guardrail Barrier​





Product Introduction

The Safety highway roller barrier is mainly composed of rotating barrels, columns, beams, swing rings, buckles, sleeves, ends, reflective strips and bolts. It adopts the "one column and four columns" method to strengthen the performance and installation of the columns and guardrails. Way, effectively preventing the car from crossing the fence and driving out of the driving lane.



New Road Crash Barrier ISO Standard Rolling Guardrail Barrier 0New Road Crash Barrier ISO Standard Rolling Guardrail Barrier 1New Road Crash Barrier ISO Standard Rolling Guardrail Barrier 2



Working principle



The Safety highway roller barrier pioneered a rotating structure to support the flexible and anti-collision and wear-resistant rotating bucket on the column, so that the rotating bucket can rotate freely on the column, through the freedom of the rotating bucket The rotation decomposes the impact force of the car, so that the impact force perpendicular to the guardrail is decomposed to the direction parallel to the guardrail, which is effectively absorbed and reduced by the rotating barrel, thereby effectively reducing the consequences of traffic accidents.

New Road Crash Barrier ISO Standard Rolling Guardrail Barrier 3New Road Crash Barrier ISO Standard Rolling Guardrail Barrier 4New Road Crash Barrier ISO Standard Rolling Guardrail Barrier 5



Product Components And Specifications

The rotary anti-collision guardrail is composed of rotating barrel, beam, column, reflective strip, casing, rotating coil and connecting piece.

The exploded view is as follows:



New Road Crash Barrier ISO Standard Rolling Guardrail Barrier 6New Road Crash Barrier ISO Standard Rolling Guardrail Barrier 7New Road Crash Barrier ISO Standard Rolling Guardrail Barrier 8New Road Crash Barrier ISO Standard Rolling Guardrail Barrier 9



Products specification
Roller (royalty barrel) H240xφ350mm,H270xφ350
Post φ140x2200x4.5mm
Cross beam 100x80x4.0mm
Connecting rack 430x84x70x4.0mm
U shape frame 380x70x6.0mm
Turning circle φ182xφ145x2.0mm
Square buckle 46x64x4.0mm
Terminal 1300x230x2.0mm
Bolts&Nuts M20x60/120/140mm





Rotary anti-collision guardrail constitutes the outline - the deviation of the outer dimensions of the rotating anti-collision guardrail member is allowed 5%



Easy to install



The new rotary anti-collision guardrail series adopts modular design, the whole

installation is simple and quick, no need for professional guidance, the installation is

safe and pollution-free, and the installation cost is low.



New Road Crash Barrier ISO Standard Rolling Guardrail Barrier 10New Road Crash Barrier ISO Standard Rolling Guardrail Barrier 11New Road Crash Barrier ISO Standard Rolling Guardrail Barrier 12



Company Profile



Taicheng Transportation Independents research and development, the self-designed anti-shock energy-absorbing highway roller barriers( new rotary anti-collisionguardrail )broke the technical monopoly of Korean American countries, filled the market gap of China's rotary guardrail, and was praised by the industry as “China's guardrail technology milestone ”.



The product has more than 20 national patents, successfully passed the collision test of small cars (house cars), buses and large trucks in the highway test site of the Ministry of Communications, and the test results and collision data are at the international leading level.
