Safety Bucket Roller Barrier Anti Collision

Safety Bucket Roller Barrier Anti Collision
Safety Bucket Roller Barrier Anti Collision
video play

Large Image :  Safety Bucket Roller Barrier Anti Collision

Product Details:
Place of Origin: China
Brand Name: Henger
Certification: SB,CIC
Model Number: 700
Payment & Shipping Terms:
Minimum Order Quantity: 100 meters
Packaging Details: Wooden Box/ Nude
Delivery Time: 7-30 days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Detailed Product Description
Features: Anti-corrosion, High Tempreture Resistance, Low Friction Product Name: Roller Barrier
Material: Polyurethane, Hot Galvanized Steel Brand: Henger
Application: Highway, Tunnel, Bridge Warranty: 12 Months
Certificate:: SB,ISO9001,CIC Color: Yellow, Orange, As You Required
High Light:

Anti Collision Bucket Roller Barrier

,

Safety Bucket Roller Barrier

,

CIC Roller Crash Barrier

Safety Anti Collision Bucket Roller Barrier



Safety Anti Collision Bucket Roller Barrier Introduction



Roller Barrier with "one upright four guardrails", can prevent the car through the fence, out of the driving lane effectively by strengthening the performance and installation of upright and guardrails. Roller Barrier use a rotating structure, install the roller barrier on the upright and make it rotate freely. This free rotation can disassemble the force of percussion from the car. And it will be adsorbed and reduced by the roller barrier effectively. So it can decrease the influence caused by traffic accidents. rolling system will create a new traffic protection way.



Product Name Roller barrier
Material Polyurethane, hot galvanized steel
Color Yellow, Orange, As you required
Used Highway, tunnel, bridge
Features Anti-corrosion, high tempreture resistance, low friction



Safety Bucket Roller Barrier Anti Collision 0





Safety Anti Collision Bucket Roller Barrier Application



1. Curved Median Strip

2. Curved Ramp

3. Diverging Point

4. Curved Tunnel

5. Curved Downhill

6. Passge Intersection

7. School Zone etc.



Safety Bucket Roller Barrier Anti Collision 1





Safety Anti Collision Bucket Roller Barrier Features



1.Reduce speed by stopper board

2. Guide reflective leads a driver to drive safely

3. Recyclable material (eco-friendly)

4. Help a vehicle turn back to the road by its spinning when the car crashed the rollers laterally

5. Minimize fatal damage of people and vehicles by absorbing collision shock

6. Reduce costs in repairing and maintenance due to Roller’s resilience.

7. Stopper boards help prevent larger accidents by slowing down Roller’s spin

8. Can be used for many years, less cost.



Safety Bucket Roller Barrier Anti Collision 2



How safety roller barrier works?



1. The roller barrier converts great shock from vehicle collision to rotational energy to absorb shock.

2. Upper and lower frames adjust tires of large and small vehicles to prevent the steering system function loss.

3. The three-dimensional structure of D-shaped frame and buffering bracket distribute and absorb the 2nd shock.

4. Props at an interval of 0.7 m increase bearing power to prevent accident vehicles from going over the guardrail and turning over into a dangerous area.

5. The product has a rotating barrel made of EVA with excellent shock absorption power, three-dimensional buffering frames and dense props supporting the frames.



Safety Bucket Roller Barrier Anti Collision 3



Safety Anti Collision Bucket Roller Barrier Working principle



The highway protective rolling guardrail mainly adopts the "one column and four beams " method . By strengthening the performance and installation method of the column and the fence, it effectively prevents the car from crossing the fence and driving out of the driving lane.





On the other hand, the new anti-collision bucket guardrail has a built-in anti-impact energy-absorbing rotary anti-collision barrel, and the flexible barrel with anti-collision



and energy absorption is mounted on the column, so that the rotating barrel can rotate freely on the column. By the free rotation of the rotating bucket, the impact force of the car is decomposed, and the impact force perpendicular to the direction of the guardrail is decomposed into a direction parallel to the guardrail, so that the impact force is effectively absorbed and reduced by the rotating barrels , thereby effectively reducing the possibility of traffic accidents .



The highway protective rolling guardrail is made of EVA and polyurethane composite. This high-strength EVA and polyurethane material itself has elastic and anti-collision and wear-resistant advantage. It can prevent the rotating barrel from being crushed when it is impacted and effectively protecting the guardrail and the passengers. Besides the well anti-collision and wear resistance, it also has the advantages of chemical corrosion resistance, UV aging resistance, weather resistance, etc. It is not easy to break, and the appearance is exquisite and not easy to fade. Under outdoor natural conditions, the service life is at least ten years.



Safety Bucket Roller Barrier Anti Collision 4



Safety Anti Collision Bucket Roller Barrier Application



1. Curved Median Strip

2. Curved Ramp

3. Diverging Point

4. Curved Tunnel

5. Curved Downhill

6. Passge Intersection

7. School Zone etc.



Safety Anti Collision Bucket Roller Barrier Shipping Details



No. Product Specifications 40*HQ Container Shipping Capacity
1. 1000 mm Column Space Barriers size : 350*500 MM 280 Meters
2. 700 mm Column Space Barriers size : 350*500 MM 240 Meters
