Highway Rolling Guardrail Barrier For Vehicle Traffic Protection

China Qingdao TaiCheng transportation facilities Co.,Ltd. certification
China Qingdao TaiCheng transportation facilities Co.,Ltd. certification
I am very grateful to the staff of Taicheng for their cooperation. Our guardrail installation is very beautiful, and my customers like it too. Next time I will buy back.

—— Le Thao

I'm Online Chat Now

Highway Rolling Guardrail Barrier For Vehicle Traffic Protection

Highway Rolling Guardrail Barrier For Vehicle Traffic Protection
Highway Rolling Guardrail Barrier For Vehicle Traffic Protection
video play

Large Image :  Highway Rolling Guardrail Barrier For Vehicle Traffic Protection

Product Details:
Place of Origin: QingDao
Brand Name: TaiCheng
Certification: ISO
Model Number: RBD245
Payment & Shipping Terms:
Minimum Order Quantity: 100 meters / Unit
Packaging Details: Pallet / wooden boxes / Suitable packaging
Delivery Time: 15-20 Days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100 Meters Per 25 Days Or More Less Time
Detailed Product Description
Material: Q235,EVA Color: Yellow,Orange
Application: Roadway Safety,Highway Surface Treatment: Hot Dipped Galvanized
Product Name: Road Rolling Barrier,Haghway Guardrail Feature: Great Corrosion Resistant,Two Waves Guardrail
High Light:

Traffic Protection Rolling Guardrail Barrier

,

Q235 Material Rolling Guardrail Barrier

,

Highway Roller Safety Barrier

Highway Rolling Guardrail Barrier for Vehicle Traffic Protection





1. Product Introduction

Rolling system with "one upright four guardrails", can prevent the car through the fence, out of the driving lane effectively by strengthening the performance and installation of upright and guardrails. Rolling system use a rotating structure, install the roller barrier on the upright and make it rotate freely. This free rotation can disassemble the force of percussion from the car. And it will be adsorbed and reduced by the roller barrier effectively. So it can decrease the influence caused by traffic accidents. rolling system will create a new traffic protection way.
Highway Rolling Guardrail Barrier For Vehicle Traffic Protection 0
2. Product Parameters

No.

Name

Specifications(mm)

Material

1

Roller

345*490/350*510(Customized)

Polyurethane

2

Post

140*2000*4.5(Customized)

Q235

3

PVC Tube

160*500*6.5(Customized)

PVC

4

Beam

100*80*4.0

Q235

5

Rolling Circle

182×145×6.0

Polymer Ethylene

6

End Socket

1300×230×4.0

Q235

7

Post Cap

145×145

Rubber

8

Bolt

M18*120

Q235



M18*180

Q235



M18*80

Q235

9

Nut

M20

Q235



Item

Specifications

Apparent Density (KG/m³)

≥125

Tensile Strength(MPa)

≥1.15

Elongation(%)

≥320

Compression Permanent Distortion (%)

≥38

Resilience(%)

≥72

Highway Rolling Guardrail Barrier For Vehicle Traffic Protection 1



3. How safety roller barrier works?




1. The rotating barrel converts great shock from vehicle collision to rotational energy to absorb shock.
2. Upper and lower frames adjust tires of large and small vehicles to prevent the steering system function loss.
3. The three-dimensional structure of D-shaped frame and buffering bracket distribute and absorb the 2nd shock.
4. Props at an interval of 0.7 m increase bearing power to prevent accident vehicles from going over the guardrail and turning over into a dangerous area.
5. The product has a rotating barrel made of EVA with excellent shock absorption power, three-dimensional buffering frames and dense props supporting the frames.

Highway Rolling Guardrail Barrier For Vehicle Traffic Protection 2


4. FAQ

1. Are you a trader or factory?
Yes,our factory is in Shandong,China.

2. How can i get a sample if i want to test the quality?
Yes,we would offer the samples.If you want to test the quality,please let me know and i would arrange you the samples.

3. How long is your delivery time?
We would offer you a best delivery time.we have a big factory,and our output would be more than 100 thousand tons per month.

4. What is your payment terms?
We accept T/T, L/C.
