Product Details:
Payment & Shipping Terms:
|
| Brand Name: | Taicheng | Product Name:: | Safety Roller Barrier |
|---|---|---|---|
| Material: | PU/EVA+Galvanized Beam | Usage: | Road Traffic Safety |
| Size: | 1.2 M*1 M* 1.2 M Or Custom | Color: | Yellow,Orange |
| High Light: | PU EVA Road Safety Highway Guardrail,Galvanized Beam Highway Guardrail,Q345B Rolling Guardrail Barrier |
||
1. Features of the Rotating Crash Barrier:
Function 1) and function 2) are the anti-collision function of the guardrail. The anti-collision function of the guardrail is the function that should be possessed to prevent the vehicle from rushing out or turning over the road or under the bridge when a large vehicle collides with the guardrail, causing a serious and vicious accident. .
Function 3 is the guiding function of the guardrail. The guiding function of the guardrail means that the vehicle can be correctly guided after the collision. The collision vehicle should not drive into the adjacent lane as much as possible within a certain distance, and it should be able to effectively block the vehicle and guide the vehicle. If the vehicle crosses, climbs, rides, or goes under the guardrail in any form, the vehicle should maintain a normal running posture after the collision, and no sideways, U-turns, etc. will occur.
Function 4) is the buffering function of the guardrail. The buffering function of the guardrail means that the guardrail can absorb the impact energy through its own deformation, or promote the energy conversion of the vehicle through the guardrail guidance, increase the release time of the impact energy, and decompose the buffering collision process to reduce vehicle damage. occupant injury.
2. Product Introduction
| name | highway guardrail safety roller barrier | use | road safety |
| size | 4130*310*81*2.75 | standard | American standard |
| material | Q345B or Q235B | feature | anti-corrision |
| certificate | ISO SGS BV CE | treatment of surface | hot dip galvanized |
Product Structure
Parts and Installation:
1) Column: It is driven into the roadbed and is the main force-bearing component.
2) Beam: It is used for the connection between the columns and to fix the rotating barrel.
3) Rotary barrel: It is fixed between the upper and lower beams and can be rotated around the column. The main materials are EVA (ethylene-ester acid copolymer) and polyurethane.
4) Sleeve: installed on the inner wall of the rotating barrel, the contact part of the rotating function.
5) Gyratory ring: Installed between the rotating barrel and the beam to balance and promote rotation.
6) Connecting frame: used for connection between beams.
7) U-shaped frame: connect the beam and the column to fix the beam.
8) Pad buckle: Lined with the beam and connected to the U-shaped frame.
9) Hoop: connecting beam and column, used to fix the beam, suitable for specific models.
10) Reflective strips.•It is a reflective film, which is pasted on the rotating barrel and plays an inductive role.
Experimental case
3. Product Parameters
| No. | Name | Specifications(mm) | Material |
| 1 | Roller | 345*490/350*510(Customized) | Polyurethane |
| 2 | Post | 140*2000*4.5(Customized) | Q235 |
| 3 | PVC Tube | 160*500*6.5(Customized) | PVC |
| 4 | Beam | 100*80*4.0 | Q235 |
| 5 | Rolling Circle | 182×145×6.0 | Polymer Ethylene |
| 6 | End Socket | 1300×230×4.0 | Q235 |
| 7 | Post Cap | 145×145 | Rubber |
| 8 | Bolt | M18*120 | Q235 |
| M18*180 | Q235 | ||
| M18*80 | Q235 | ||
| 9 | Nut | M20 | Q235 |
| Item | Specifications |
| Apparent Density (KG/m³) | ≥125 |
| Tensile Strength(MPa) | ≥1.15 |
| Elongation(%) | ≥320 |
| Compression Permanent Distortion (%) | ≥38 |
| Resilience(%) | ≥72 |
Key Features
Our services
| A | High quality goods with competitive price and fast delivery time. |
| B | Technical help with the solutions and questions. |
| C | OEM design,customized drawing for the guardrail and pipe. |
| D | Different standard products we would offer for different country and regions. |
| E | Different color and surface treatment,cold galvanized+spray, hot galvanized,hot galvanized+spray. |
