Product Details:
Place of Origin: QingDao
Brand Name: TaiCheng
Certification: ISO
Model Number: RBD245
Payment & Shipping Terms:
Minimum Order Quantity: 100 meters / Unit
Price: USD 245 Each Meters
Packaging Details: Pallet / wooden boxes / Suitable packaging
Delivery Time: 15-20 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 Meters Per 25 Days Or More Less Time
Detailed Product Description
Roller Material: EVA / PU / Polyurethane Specification: Beam 1/2/3/4/5PCS
Spacing: 650/700/1000 MM Metal Material: Q235 Hot-dip Galvanizing
Grade: International Level 4 Color: Orange / Yellow / Red / Green
Lifetime: 10 Years Usage: Road Traffic Safety,Highway And Bridge Safety
High Light:

Anticollision Tube Highway Guide Rail

,

EVA Rotating Barrel Highway Guide Rail

,

Level 4 Anticollision Tube Guardrail

Rotating Barrel Highway Guide Rail Anticollision Tube Guardrail

Product Description

Design concept of crash barrier:

According to the "Code for Design of Highway Traffic Safety Facilities" (JTG D81-2006), the guardrail is defined as (Article 2.0.1), as a longitudinal energy-absorbing structure, the guardrail absorbs collision energy through self-deformation or vehicle climbing, thereby Change the driving direction of the vehicle, prevent the vehicle from going off the road or entering the opposite lane, and minimize the injury to the occupant. Under the set impact conditions, the guardrail shall have the following functions:

1) Prevent vehicles from going off the road or crossing the median into the opposite lane;

2) Prevent the vehicle from drilling out from under the guardrail, or breaking the guardrail;

3) The guardrail should enable the vehicle to return to the normal driving direction;

4) Minimal damage to passengers in the event of a collision;

5) Can induce the driver's sight.

EVA Rotating Barrel Highway Guide Rail Anticollision Tube Guardrail 0

EVA Rotating Barrel Highway Guide Rail Anticollision Tube Guardrail 1







Specification
item
value
Place of Origin
Qingdao
Brand Name
Taicheng
Product name
Safety Roller Barrier
Material
PU/EVA+Galvanized Beam
Usage
Road Traffic Safety
Size
1.2 m*1 m* 1.2 m or Custom
Color
Yellow,Orange
Standard
AISI,GB,JT/T281/AASHTO M180
EVA Rotating Barrel Highway Guide Rail Anticollision Tube Guardrail 2
Product Material
The anti-impact energy-absorbing rotating anti-collision barrel is made of high-tech polymer composite material---polyurethane ,
which is made in one time . Polyurethane material has high strength of polyethylene material and high elasticity of rubber
material , so the barrel itself has high elasticity and anti-collision and wear-resistant characteristics, which can avoid being
crushed when impacted, and effectively Protecting to the fence and the passengers.
EVA Rotating Barrel Highway Guide Rail Anticollision Tube Guardrail 3
Product Components And Specifications
The rotary anti-collision guardrail is composed of rotating barrel, beam, column, reflective strip, casing, rotating coil and
connecting piece.
The exploded view is as follows:
EVA Rotating Barrel Highway Guide Rail Anticollision Tube Guardrail 4
Easy to install
The new rotary anti-collision guardrail series adopts modular design, the whole installation is simple and quick, no need for professional guidance, the installation is safe and pollution-free, and the installation cost is low.
Company Profile
EVA Rotating Barrel Highway Guide Rail Anticollision Tube Guardrail 5
Qingdao Taicheng Transportation Facilities Co., Ltd. ( Taicheng ) is a technology based innovation enterprise invested by Henger Group . It is headquartered in Jinkou Industrial Park, Qingdao. Taicheng Transportation has an innovative research team, advanced manufacturing technology, first-class production facilities and perfect testing methods. Reliable productquality, enthusiastic after-sales service, dedicated to the great cause of improving road safety in China.
Taicheng Transportation Independents research and development, the self-designed anti-shock energy-absorbing highway roller barriers ( new rotary anti-collision guardrail )broke the technical monopoly of Korean American countries, filled the market gap of China's rotary guardrail, and was praised by the industry as “China's guardrail technology milestone ”
