| Name: | Roller Barrier, Safety Barricade, Removable Bollard, Car Parking Advertising Boom Gate Barrier | Roller Material: | EVA / PU / Polyurethane |
|---|---|---|---|
| Roller Size: | Diameter 245/350 Mm | Spacing: | 650/700/1000 Mm |
| Usage: | Road Traffic Safety, For Dancing And Singing, ROAD SIDE, Curve Roads, Safety Roller Barrier Boad Safety Barrier | Size: | 4320x310x85x3mm,352X352X1020mm,D350*H500mm(Single),H240/270xD350mm |
| Type: | W-beam,Double Buckets Or Single Bucket,Traffic Barrier | Standard: | AASHTO M180,GB JT/T281-2007,EN1317 |
| High Light: | highway crash barrier,road protection barriers,Polyurethane Roller Guardrail |
||
Road Traffic Highway Roller Barrier Polyurethane Roller Guardrail RBD245
1. Company Situation
Qingdao Taicheng Transportation Facilities Co., Ltd. is located in Jinkou Town, Jimo District, Qingdao City, Shandong Province. It is a professional rotating guardrail manufacturer with advanced technology and strong strength, which integrates development, production and sales.
Our advantages lie in independent production, factory direct operation, exquisite workmanship, precise size, professional technicians, high quality production level is the cornerstone of our development.
2. Product Introduction
Accessories:
Crash barrier >>>
Cold roll formed section
3mm /2.7mm thick HR sheet.
S235JR/S275JR/S355JR grade steel or equivalent
Hot dip galvanised - 550 gms/m2 or 460 gms/m2
Yield Strength: 240-310 N/mm2
Tensile Strength: 410-490 N/mm2
Elongation: 15-25%
Post >>>
Anchored to foundation on Ground & Bridges
Channel section of 75x150x75x5mm
5mm thick HR sheet
S235JR/S275JR/S355JR grade steel or equivalent
Hot dip galvanised -550 gms/m2 or 610 gms/m2
Spacer >>>
Buffer between Post & barrier
Channel section of 150x75x5mm.
5mm thick HR sheet
S235JR/S275JR/S355JR grade steel or equivalent
Hot dip galvanised -550 gms/m2 or 610 gms/m2
Roller barrier >>>
3. Product Parameters
|
No. |
Name |
Specifications(mm) |
Material |
|
1 |
Roller |
345*490/350*510(Customized) |
Polyurethane |
|
2 |
Post |
140*2000*4.5(Customized) |
Q235 |
|
3 |
PVC Tube |
160*500*6.5(Customized) |
PVC |
|
4 |
Beam |
100*80*4.0 |
Q235 |
|
5 |
Rolling Circle |
182×145×6.0 |
Polymer Ethylene |
|
6 |
End Socket |
1300×230×4.0 |
Q235 |
|
7 |
Post Cap |
145×145 |
Rubber |
|
8 |
Bolt |
M18*120 |
Q235 |
|
|
M18*180 |
Q235 |
|
|
|
M18*80 |
Q235 |
|
|
9 |
Nut |
M20 |
Q235 |
|
Item |
Specifications |
|
Apparent Density (KG/m³) |
≥125 |
|
Tensile Strength(MPa) |
≥1.15 |
|
Elongation(%) |
≥320 |
|
Compression Permanent Distortion (%) |
≥38 |
|
Resilience(%) |
≥72 |
4. What are the details of our Safety Railing?
1, Powder coated for internal use or Galvanised & powder coated for external use
2, Quality and strength combined with modular design for quick and easy installation
3, Finished in a high visibility yellow colour,there is little chance of them being ignored.
4, Counter sunk bolts secure rails to posts (damaged sections easily replaced)
5, Easy to extend / modify at any stage
6, Base plate measures 200mm x 200mm x 10mm.
7, Perfect for heavy duty protection
8, Strong and durable.
5. Henger's Products Advantage
|
A .The roller barrel is made of EVA and polyurethane composite material. |
This kind of high strength EVA and polyurethane material is elastic and anti-impact and wear-resistant, which can avoid crashing of the roller barrel. when it is impacted, can effectively protect the guardrail and driver and passengers. |
|
B. In addition to good anti-collision and wear-resisting performance. |
It also has the advantages of anti-chemical corrosion, anti-ultraviolet aging, weathering resistance and so on. It is not easy to be damaged, and its appearance is exquisite and not faded. |
|
C.The roller barrel also has very strong resilience. |
Even if they are seriously hit, they can be immediately restored to their original form. |
|
D. The roller barrel has bright color, such as yellow, orange, green, etc., and has high bright reflection effect. |
It has eyeball capture function, which can arouse the attention of the driver and reduce the accident rate. Especially to ensure their safety at night and on rainy days. |
6. Packing and shipping
For the roller barrel,it would be packed with opp bag+woven bag,or opp bag+woven bag+carton.
And for the guardrail,it would be packed as tie,and also the same as post.Shipping by air or sea as request.
7.Our services
We are special in the corrugated beam highway guardrail and corrugated Steel Pipe for traffic and would offer you much supports.
1) High quality goods with competitive price and fast delivery time.
2) Technical help with the solutions and questions.
3) OEM design,customized drawing for the guardrail and pipe.
4) Different standard products we would offer for different country and regions.
5) Different color and surface treatment,cold galvanized+spray, hot galvanized,hot galvanized+spray.
8. FAQ
|
Q1 |
Are you a trader or factory? |
|
R1 |
Yes,our factory is in Shandong,China. |
|
Q2 |
How can i get a sample if i want to test the quality? |
|
R2 |
Yes,we would offer the samples.If you want to test the quality,please let me know and i would arrange you the samples. |
|
Q3 |
How long is your delivery time? |
|
R3 |
We would offer you a best delivery time.we have a big factory,and our output would be more than 100 thousand tons per month. |
|
Q4 |
What is your payment terms? |
|
R4 |
We accept T/T, L/C. |
