| Spacing: | 650/700/1000 Mm | Metal Material: | Q235 Hot-Dip Galvanizing |
|---|---|---|---|
| Feature: | Easily Assembled, High Intensity, Eco Friendly, Corrosion Resistant | Grade: | International Level 4 |
| Specification: | Beam 1/2/3/4/5 Pcs | Weight: | 7-15 Kgs, As Per Size Of The Product, 30kg |
| Standard: | AASHTO M180,GB JT/T281-2007 | Height: | 95cm,500mm,1800mm |
| Size: | 4320x310x85x3mm,352X352X1020mm | Zinc Coating: | 85um(600g/m2),550-1100g/m2 |
| Highlight: | highway safety barriers,road protection barriers,Road Corners Highway Roller Barrier |
||
Road Corners Highway Roller Barrier , Anti Corrosion Rolling Guard Barrier
1. Company Situation
Qingdao Taicheng Transportation Facilities Co., Ltd. is located in Jinkou Town, Jimo District, Qingdao City, Shandong Province. It is a professional rotating guardrail manufacturer with advanced technology and strong strength, which integrates development, production and sales.
Our advantages lie in independent production, factory direct operation, exquisite workmanship, precise size, professional technicians, high quality production level is the cornerstone of our development.
2. Product Introduction
Pioneer industry, leading professional:
1). High temperature hot dipping zinc.
2). High temperature curing process.
3). The unique security design.
4). Rust, anti-corruption.
5). Innovation, safety, no rust.
| Surface Treatment | Hot dipped galvanized |
| Zinc coating | 85um(600g/m2) |
| The thickness | 3 mm,4 mm,6 mm or according to customers’request |
| The thickness of galvanized | 60-600um or according to customers’ request |
| Base steel | Steel Grade Q235B (equivalent to S235JR according to DIN EN 10025 and Gr. D according to ASTM A283M) |
| Standards | GB/T18226,JT/T281-1995,AASHTO,M-180,RAL-RG620,SPS98S or any other International Standards |
| Certificate | ISO 9001,Russian impacting test report |
| Features | High intensity,durable,anti-rusting,anti-corrosion |
| Application | Highway,bridge,curves and slopes,parking lots,road corners, dead end street etc. |
3. Product Parameters
| No. | Name | Specifications(mm) | Material |
| 1 | Roller | 345*490/350*510(Customized) | Polyurethane |
| 2 | Post | 140*2000*4.5(Customized) | Q235 |
| 3 | PVC Tube | 160*500*6.5(Customized) | PVC |
| 4 | Beam | 100*80*4.0 | Q235 |
| 5 | Rolling Circle | 182×145×6.0 | Polymer Ethylene |
| 6 | End Socket | 1300×230×4.0 | Q235 |
| 7 | Post Cap | 145×145 | Rubber |
| 8 | Bolt | M18*120 | Q235 |
| M18*180 | Q235 | ||
| M18*80 | Q235 | ||
| 9 | Nut | M20 | Q235 |
| Item | Specifications |
| Apparent Density (KG/m³) | ≥125 |
| Tensile Strength(MPa) | ≥1.15 |
| Elongation(%) | ≥320 |
| Compression Permanent Distortion (%) | ≥38 |
| Resilience(%) | ≥72 |
4. Product use
The rotating guardrails are especially suitable for installation and application in many accident areas such as tunnel entrances, central isolation belts, rapid turning zones, and complex intersections.
1) Road central safety roller.the road central safety roller is to divide the car line and prevent safety driving from opposite impact .
2) Road cross safety roller.the road cross safety roller is installed on the cross to prevent the cars from rushing to the greenbelt.
3) Safety roller for highway.it is very fast driving in the highway, and the safety roller is to protect the drivers&passengers from accident.
5. Packing and shipping
For the roller barrel,it would be packed with opp bag+woven bag,or opp bag+woven bag+carton.
And for the guardrail,it would be packed as tie,and also the same as post.Shipping by air or sea as request.
6. Henger's Products Advantage
1) The roller barrel is made of EVA and polyurethane composite material.
This kind of high strength EVA and polyurethane material is elastic and anti-impact and wear-resistant, which can avoid crashing of the roller barrel. when it is impacted, can effectively protect the guardrail and driver and passengers.
2) In addition to good anti-collision and wear-resisting performance.
It also has the advantages of anti-chemical corrosion, anti-ultraviolet aging, weathering resistance and so on. It is not easy to be damaged, and its appearance is exquisite and not faded. In the outdoor natural conditions, the service life is more than 10 years. Once a traffic accident occurs, when the car hits it, the energy of the collision is converted into the rotational energy by the way of rotation, so as to maintain the normal driving direction and speed of the car, so as to minimize the incidence of traffic accidents. To protect the safety of human life and provide a new road safety protection.
3) The roller barrel also has very strong resilience.
Even if they are seriously hit, they can be immediately restored to their original form.
