Product Details:
Payment & Shipping Terms:
|
| Roller Size: | Diameter 245/350 Mm | Color: | Orange / Yellow / Red / Green |
|---|---|---|---|
| Roller Material: | EVA / PU / Polyurethane | Specification: | Beam 1/2/3/4/5 Pcs |
| Metal Material: | Q235 Hot-Dip Galvanizing | Name: | Roller Barrier, Safety Barricade, Removable Bollard, Car Parking Advertising Boom Gate Barrier |
| Usage: | Road Traffic Safety, For Dancing And Singing, ROAD SIDE, Curve Roads, Safety Roller Barrier Boad Safety Barrier | Application: | Roadway Safety,Outdoor,Highway |
| Technology: | Cold Rolled,Cold Rolling | ||
| High Light: | road roller barrier,roller safety barrier,High Security Rolling Guardrail Barrier |
||
High Security Rolling Guardrail Barrier Impact Resistance Eco Friendly
1. Product Introduction
|
Surface Treatment |
Hot dipped galvanized |
|
Zinc coating |
85um(600g/m2) |
|
The thickness |
3 mm,4 mm,6 mm or according to customers’request |
|
The thickness of galvanized |
60-600um or according to customers’ request |
|
Base steel |
Steel Grade Q235B (equivalent to S235JR according to DIN EN 10025 and Gr. D according to ASTM A283M) |
|
Standards |
GB/T18226,JT/T281-1995,AASHTO,M-180,RAL-RG620,SPS98S or any other International Standards |
|
Certificate |
ISO 9001,Russian impacting test report |
|
Features |
High intensity,durable,anti-rusting,anti-corrosion |
|
Application |
Highway,bridge,curves and slopes,parking lots,road corners, dead end street etc. |
The rotating guardrail combines the advantages of traditional barrier and new type energy -absorption anti-collision roller barrel. It inserts the anti-collision roller barrel into strengthened traditional barrier. When traffic accident happening, the roller barrel can rotate freely on the columns, and through this free rotation of the roller, they break down the impact force of the car. it can efficiently resolve the impact energy by converting the impact energy to rotational energy and pull the accident car back to normal motion trail.
2. Product Parameters
|
No. |
Name |
Specifications(mm) |
Material |
|
1 |
Roller |
345*490/350*510(Customized) |
Polyurethane |
|
2 |
Post |
140*2000*4.5(Customized) |
Q235 |
|
3 |
PVC Tube |
160*500*6.5(Customized) |
PVC |
|
4 |
Beam |
100*80*4.0 |
Q235 |
|
5 |
Rolling Circle |
182×145×6.0 |
Polymer Ethylene |
|
6 |
End Socket |
1300×230×4.0 |
Q235 |
|
7 |
Post Cap |
145×145 |
Rubber |
|
8 |
Bolt |
M18*120 |
Q235 |
|
|
M18*180 |
Q235 |
|
|
|
M18*80 |
Q235 |
|
|
9 |
Nut |
M20 |
Q235 |
|
Item |
Specifications |
|
Apparent Density (KG/m³) |
≥125 |
|
Tensile Strength(MPa) |
≥1.15 |
|
Elongation(%) |
≥320 |
|
Compression Permanent Distortion (%) |
≥38 |
|
Resilience(%) |
≥72 |
3. Product use
|
A |
Road central safety roller.the road central safety roller is to divide the car line and prevent safety driving from opposite impact |
|
B |
Road cross safety roller.the road cross safety roller is installed on the cross to prevent the cars from rushing to the greenbelt. |
|
C |
Safety roller for highway.it is very fast driving in the highway, and the safety roller is to protect the drivers&passengers from |
4. Features of construction barrier:
1. Normal Size: 3200/3810/4000/4300/4320×306/310/312/380×80/82/83/85×2.75/3/4mm. Available in different sizes.
2. Profile: W-beam, Three-beam construction barrier.
3. Applicable Standards: JT/T281-1995(Corrugated Sheet Steel Beams For Expressway construction barrier - China), AASHTO M-180(Corrugated Sheet Steel Beams For construction barrier - USA), RAL-RG620 (German) or any other International Standards.
4. Surface Treatment: Hot dip galvanized or Power coated.
5. The Thickness of Galvanized (Double Sides): 100g/m2,300g/m2,600g/m2 or as per your request.
6. Features: Great corrosion resistant, high intensity, long and durable, with good impact resistance, low cost, long life, higher security, environmental protection, etc.
7. Relevant Parts Required for construction barrier: post, spacer (C, U and Sigma types etc) and fasteners.
8. Other special specification as per client's requirement or drawings.
5. Packing and shipping
For the roller barrel,it would be packed with opp bag+woven bag,or opp bag+woven bag+carton.
And for the guardrail,it would be packed as tie,and also the same as post.Shipping by air or sea as request.
6. Our services
We are special in the corrugated beam highway guardrail and corrugated Steel Pipe for traffic and would offer you much supports.
1) High quality goods with competitive price and fast delivery time.
2) Technical help with the solutions and questions.
3) OEM design,customized drawing for the guardrail and pipe.
4) Different standard products we would offer for different country and regions.
5) Different color and surface treatment,cold galvanized+spray, hot galvanized,hot galvanized+spray.
7. FAQ
1. Are you a trader or factory?
Yes,our factory is in Shandong,China.
2. How can i get a sample if i want to test the quality?
Yes,we would offer the samples.If you want to test the quality,please let me know and i would arrange you the samples.
3. How long is your delivery time?
We would offer you a best delivery time.we have a big factory,and our output would be more than 100 thousand tons per month.
4. What is your payment terms?
We accept T/T, L/C.
