Highway Traffic Safety With Traffic Fence Barrier With Rotating Guardrail Safer Guardrail
Parts and installation:
1) Column: It is driven into the roadbed and is the main force-bearing component.
2) Crossbeam: used for the connection between the columns and fix the rotating barrel.
3) Rotating barrel: It is fixed between the upper and lower beams and can be rotated around the column. The main materials are EVA (ethylene-ester acid copolymer) and polyurethane.
4) Sleeve: Installed on the inner wall of the rotating barrel, rotating contact part.
5) Swivel ring: installed between the rotating barrel and the beam to balance and promote rotation.
6) Connection frame: used for connection between beams.
7) U-shaped frame: connect the beam and the column to fix the beam.
8) Cushion buckle: lined with beam and connected to U-shaped frame.
9) Hoop: connect the beam and column, used to fix the beam, suitable for specific models.
10) Reflective strip. It is a reflective film that is pasted on the rotating barrel for inducing.
Nominal size and tolerance of rotating barrel:
|
Type
|
Nominal size and tolerance ( mm )
|
|
D
|
345+5 -5
|
370+5 -5
|
|
h
|
490+10 -10
|
510+10 -10
|
|
d
|
151+2 -2
|
|
h1
|
110+2 -2
|
|
h2
|
50+1 -1
|
|
h3
|
80+2 -2
|
